DIGITAL FLAME DETECTOR
Explosion-proof infrared (IR3) digital flame detector
IRT-001-K
Ultra-small Digital Infrared Three-wavelength Flame Detector
State-of-the-art technology that improved dramatically the alarms for non-fire situations
The effective sensing distance sensitivity can be maintained as it is from the energy source emitting flame-like energy.
- Stylish design
- Weight: 650g (including cable gland)
- Size: diameter 50mm / length 46mm
| Test subject for the alarms for non-fire situations |
Specification | Test distance & condition | Number of detection for non-alarm situations / Total number of test samples |
| Electric stove | 800W, 970kcal/h | 1~3m Human body walking round, artificial flicker |
0 units /80 units |
| Rotary gas heater | LNG, 9700kcal/h | 7m Human body walking round, artificial flicker |
0 units /80 units |
| Halogen lamp without the front window | 24W | Proximity Distance Detector window Close-up for 30 seconds |
0 units /80 units |
| Co2 electric welding machine | 60A | more than 10m over 2~30 seconds continuously outdoors |
0 units /80 units |
| Human body | 1m Human hand signal, artificial flicker |
0 units /80 units |
Sample Detector: 30m 90° waterproof IR3 ※ Our test value standard
Key Technologies and Features
- Artificial intelligent flame detector with anti-false alarm algorithm
- Fast and accurate fire detection
- Excluding the alarms for non-fire situations such as hot body, arc welding, halogen lamp, sunlight, and etc.
- Long-distance fire monitoring (effective detection distance 30m)
- Reasonable economic price
- World's smallest size IR3 flame detector
- Intrinsic pressure / container dustproof type
- Sensible interior design
- Adopt the latest digital infrared 3 wavelength sensor
- Application of 4Layer optimized PCB design technology
- Application of electric noise minimization technology
- Communication interface (RS-485 optional)
- Explosion proof : Ex d ⅡC T6, Ex tD A21 IP67 T85˚C
- ATEX Explosion proof : Ex db ⅡC T6 Gb / Ex tb ⅢC T85 Db IP66/67
Main Specifications
| General | Kind | Flame Detector (IR3) |
| Type | DC24V Explosion-proof type, ordinary type, reusable type, indoor/outdoor type, infrared type, waterproof type Viewing angle 90° Cone, effective detection distance 30m |
|
| Model | IRT-001-K | |
| Enclosure | Material | Stainless steel (SUS316L) |
| Color | Silver White | |
| Electrical Specifications |
Operating voltage |
DC24V ±20% (19.2~28.8V) |
| Current | Standby 40mA when sensing, 50mA |
|
| Contact output | ON/OFF | |
| Communication port | RS-485/4~20mA (optional) | |
| Environmental Specifications |
Operating Temperature |
-40℃ ~ +85℃ |
| Operating Humidity | 0 ~ 95% | |
| Installation place | Interior / exterior of the building | |
| Other Specifications | Size | Diameter 50mm / Length 46mm |
| Weight | 650g (including cable gland) | |
| Detection window | Sapphire |
Where to apply
Industry, power plant, cultural property, gymnasium, temple, performance hall, ship, government office, high-rise building, military facility, hangar, barn and etc
