Items | Specification | Quantity | Correction target |
Remarks |
Hygrometer | (0 ~ 98) % | 1 | ||
Voltage regulator (Slidacs) |
- AC (0 ~ 250) V - Rated capacity is 3 kVA 1 |
1 | ||
Automatic voltage regulator |
Rated capacity 15 kVA 1 | 1 | ||
Sensitivity tester |
1. Sensitivity test equipment is as follows ◎ Optical base Effective test distance between the detector attachment base and the fire source: (80 ~ 900) cm ◎ Detector attachment base Detector can be installed on the attachment plate moving forward and backward (x-axis), left and right (y-axis), up and down (z-axis) and on the z axis rotating left and right(r-axis) -Works independently for each axis The r axis can be rotated forward and backward, and by 5 degrees. ◎ Combustion unit -It consists of cylinder, LPG, micro-burner and cylindrical cooling structure. ◎ Flame control unit -Function to change some length of the cylinder ◎ Chopper part -Two wings ◎ Monitor section -Ultraviolet sensor (using UV counter) and visible light, An apparatus that installs infrared sensors (using R-II type radiometer) at a certain distance ◎ Control board -Detector attachment base controller, gas flow controller, chopper controller, sensor measurement instrument for monitoring, receiver, power supply, etc. -Gas flowmeter: (10 ~ 50) Adjustable to SCCM (Standard Cubic centimeter per minute) -Number of rotations of the chopper: variable from (1 to 20) rpm 2. One that can be tested according to the provisions of Article 19-2 of the type approval standard |
1 | ||
Shockwave withstand voltage tester |
External facility use | 1 | KFI facility use | |
Sensitivity laboratory |
The ceiling is more than 1.2m away from the top of the sensitivity tester. | 1 place | Our laboratory | |
Cooling fans | 2 | |||
Thermometer | room temperature can be measured | 1 | ||
Indication thermometer |
(-20 ~ 180) °C measurement possible (minimum unit 0.1 ℃) | 1 | ○ | If one has the functions of indication thermometer and anemometer the one can used. |
Anemometer | (0 to 5) m/s measurement possible (minimum unit 0.1 m/s) | 1 | ○ | |
Vibration tester | External facility use | 1 | KFI facility use | |
Impact tester | Wood board with thickness 20mm, width 300mm, length 500mm and the stee; ball of 0.54kg, and 51mm diameter | 1 | ||
Impact Voltage Tester | External facility use | 1 | KFI facility use | |
Motion indicator | One that can indicate whether the detector is working or not | 1 | ||
Vernier caliper | (0 to 150) mm or more (minimum unit: 0.05 mm or less) | 1 | ||
Stopwatch | 60-second system | 1 | ||
Micrometer | (0 to 25) mm or more (minimum unit: 0.01 mm or less) | 1 | ○ | |
Megger | DC 500V | 1 | ○ | |
Dielectric strength tester | (0 to 3000) V (with 1 minute timer) | 1 | ○ | |
Digital multimeter | AC, DC, V, mA, Ω (minimum unit 0.1 or more) | 1 | ○ | |
AC voltage ammeter | 0.5 grade | 1 | ○ | Replace with a separate digital multimeter |
DC voltage ammeter | 0.5 grade | 1 | ○ | |
Rectifier | DC (0 ~ 30) V, (0 ~ 5) A | 1 | ○ | |
Repeating tester | The operation of the detector can be repeatedly tested 1,000 times or more. | 1 | ||
Thermo-hygrostat | -Constant temperature: (-40 ~ 150) ℃ (minimum unit 1 ℃ or less) Humidity: (40 ~ 98)% (minimum unit: 1% or less) |
1 | ||
Corrosion test equipment | External facility use | 1 | KFI facility use |
